Apex Series

apex-building-series-britespan-systems-canada-usa

Ultra functional curved roof profile with a strong and noticeable peak.

Overview

Apex is designed with a stunning and functional variance to our dome-shaped Atlas series, showcasing a curved roof profile, with a strong and noticeable peak, and sidewall legs for increased interior space.



All Apex Series profiles meet or exceed site-specific design criteria, offering moderate to wide spans with no center load-bearing columns, and trusses that begin at 24 inches deep and up to 51.5 inches deep (approx. 61 cm to 131 cm) depending upon width and site loads.



  • Fully engineered specifically for your site location.
  • Available with a structural engineer’s seal.
  • Gable-style design & sizing in many different profiles to fit your needs.
  • Custom designs available.
  • Exceptional value.

Industry Applications

Commercial uses:



Salt and sand storage, general equipment storage, commodity storage, warehousing, maintenance building, manufacturing facility, recycling and waste management, cold storage, loading dock, transfer station, mining, landscape equipment storage, construction, retail equipment storage, transportation and distribution, government and municipal buildings, energy, oil and gas, retail.



Agricultural uses:



Dairy barn, beef barn, equine exercise barn, riding arena, livestock, farm equipment storage, general storage, commodity storage, composting, sheep barn, hay & straw storage, cash crops.



Municipal and Public Works uses:



Salt and sand storage, general equipment storage, commodity storage, warehousing, maintenance building, manufacturing facility, recycling and waste management, cold storage, loading dock, transfer station, mining, landscape equipment storage, construction, retail, transportation and distribution, government and municipal buildings, energy, oil and gas.



Other industry uses:



Agribusiness, automotive storage, aviation, boats/marina, break bulk, concert venues, events & hospitality, fertilizer distribution, fire halls, grain storage, hogs & swine, hospitality venues, indoor golf, lumber and logging, marine and ports, military, parks and recreation, port authority, river terminals, sport & recreation, wastewater treatment, workshop.

apex-building-series-britespan-systems-inc

Technical specifications

  • Building widths start at 53 ft. and up to 100 ft. wide (approx. 16 m to 30.5 m).
  • Can be of any length.
  • Building height and interior clearance are designed to meet the customer’s specific needs.
  • Apex series building profile is gable-styled.
  • Truss spacing is dependent on application and site loads.
  • Cover is either one piece or individual Keder panels dependent upon building width.

Engineered for your site location

apex-building-series-britespan-systems-inc

Standard features

  • Post-production hot-dipped galvanized trusses.
  • Fabrics are 12 oz & 13.5 oz High Density Polyethylene (HDPE), available in both Flame Retardant (FR) and Non-Flame Retardant (Non FR) versions.
  • Available in white, green, blue, sandstone, brown, grey, red, and black in NovaShield Non-Flame retardant; white, blue, green, grey, sandstone, and black or white mesh in Flame-Retardant fabrics.
  • Cover is either one piece or individual Keder panels dependent upon building width.
  • Standard leg heights range from 10’ to 14’. Custom leg heights can be achieved.
  • End Flaps are available in accent colours.
  • Aprons can be provided with accent colours.
apex-building-series-britespan-systems-inc

Custom options

  • Stainless steel cables.
  • Post-production hot-dipped galvanized purlins and secondaries.
  • Hot-dipped galvanized bolt package.
  • Open ended, partially enclosed or fully enclosed building.
  • Upgrade to individual Keder panels for each bay in case of high wind areas.
  • Customizable steel leg heights.
  • Custom eaves are available.
  • Chimneys/covered, ridge vents, insulation, lighting, HVAC, fire suppression and more can be added by contractor.
  • Doors can be designed into end walls.
  • Customizable side opening.
  • Open ridge vents can be included in your cover.
  • PVC (polyvinyl chloride) covers are available.
  • Elite Fabric is available as an upgrade, and it extends your warranty.
  • Branding and logo printing.

Apex Series buildings can be built on the following foundation types: blocks, containers, grade beam, helical screw, piers, poured wall, slab.
